gRPC Integrations

Internal service-to-service API for payment adapters, card processors, FX feeds, and platform microservices.

gRPC (internal): cluster-only; never routed through KrakenD.

Overview

Direction	Who calls whom	Proto package	Typical use
Inbound to finance	Adapter → finance	`finance.v1`	Transfers, card payments, FX rate publish, ledger statement export
Outbound from finance	finance → adapter	`provider.v1`	Account open/close, card issue, PAN/CVV
Platform internal	Any service → identity/compliance	`identity.v1`, `compliance.v1`	KYC gate, user lookup, step-up validation

Proto sources live in each service repository:

Service	Proto path
finance-service	`proto/finance/v1/.proto`, `proto/provider/v1/.proto`
identity-service	`proto/identity/v1/identity.proto`
compliance-service	`proto/compliance/v1/compliance.proto`

Generate Go stubs: make proto in the respective service directory.

Connectivity

Kubernetes (production / Minikube)

K8s Service	gRPC address	Listens
`finance`	`finance:9090`	`TransferService`, `CardPaymentService`, `FXRateService`, `TransactionStatementService`
`identity`	`identity:9090`	`IdentityInternal`
`compliance`	`compliance:9090`	`ComplianceInternal`

HTTP for the same pods is on port 8080 (REST). gRPC uses a separate port on the same Service object.

Environment variables (ConfigMap / Deployment):

Variable	Example	Used by
`GRPC_ADDR`	`:9090`	finance, identity, compliance (listen)
`FINANCE_GRPC_ADDR`	`finance:9090`	crypto-service, future payment adapters
`IDENTITY_GRPC_ADDR`	`identity:9090`	finance, compliance, notification, api-gateway
`COMPLIANCE_GRPC_ADDR`	`compliance:9090`	finance
`PROVIDERS_CONFIG`	`/config/providers.yaml`	finance (provider routing)

Local dev defaults (without K8s): finance gRPC localhost:9092, compliance localhost:9091, identity localhost:9090.

Call matrix

Conventions

Amounts and IDs

Amounts - decimal strings with fixed scale (e.g. "1500.00", "25.99"). Never use binary floats.

UUIDs - standard string form (550e8400-e29b-41d4-a716-446655440000).

Currency - ISO 4217, 3 letters (EUR, USD).

Actor

Every mutating finance RPC requires an Actor:

Type	When
`ACTOR_TYPE_SERVICE`	Payment/card/FX adapters, crypto-service
`ACTOR_TYPE_ADMIN`	Back-office automation (rare on gRPC)
`ACTOR_TYPE_USER`	Not used on gRPC (users go through REST + step-up)

Service actors skip user MFA but KYC checks on the account owner still apply.

Idempotency

All finance mutating RPCs require:

idempotency_key - unique per logical operation

source_service - caller identity (e.g. "currencycloud-adapter")

Uniqueness constraint: (source_service, idempotency_key). Re-sending the same pair returns the existing transfer (success with same ID), not a duplicate ledger entry.

Use provider-side IDs in keys when possible: "cc-payment-{external_id}".

Traceability fields

Field	Purpose
`external_reference`	ID in the external provider system
`source_service`	Calling service name for audit
`metadata`	Arbitrary string map (settlement refs, provider payload snippets)

Errors

Domain errors map to gRPC status codes:

gRPC code	Typical cause
`INVALID_ARGUMENT`	Missing `source_service`, bad UUID, invalid amount
`NOT_FOUND`	Transfer/account/card not found
`FAILED_PRECONDITION`	Insufficient balance, KYC blocked, wrong transfer state
`PERMISSION_DENIED`	Auth failure (when middleware enabled)
`INTERNAL`	Unexpected server error

Message text contains a human-readable reason; integrate retry only on UNAVAILABLE / INTERNAL with backoff.

Authentication (target production setup)

Documented target (not fully enforced on all servers today):

mTLS between pods in the cluster

Service JWT with claims service_id and scoped permissions, e.g.:

finance:transfer:create, finance:transfer:execute, finance:transfer:cancel

finance:card_payment:create

finance:fx_rate:upsert

Identity ValidateStepUpToken additionally requires metadata x-gateway-token when called from the api-gateway plugin.

finance.v1 - Inbound APIs (adapters call finance)

Finance exposes four gRPC services on finance:9090. All transfer and card flows converge on the same TransferPipeline used by the public REST API.

TransferService

Proto: finance-service/proto/finance/v1/transfer.proto

RPC	Purpose	Result status
`CreateTransfer`	Create internal, P2P, SWIFT, SEPA, or ACH transfer	Usually `PENDING` (hold placed)
`ExecuteTransfer`	Finalize a pending outbound rail after provider settlement	`COMPLETED`
`CancelTransfer`	Cancel before execute	`CANCELLED`
`CreditTransfer`	Admin credit - inbound funds (wire, crypto sell proceeds)	`COMPLETED`
`DebitTransfer`	Admin debit - outbound funds (crypto buy)	`COMPLETED`
`GetTransfer`	Read transfer by ID	-

Transfer types (`TransferType`)

Enum	Rail	Typical flow
`TRANSFER_TYPE_INTERNAL`	Book transfer between two platform accounts	Create → immediate complete
`TRANSFER_TYPE_P2P`	To another user (by account number / email / phone)	Create → complete
`TRANSFER_TYPE_SEPA`	SEPA credit transfer	Create (pending) → Execute
`TRANSFER_TYPE_SWIFT`	SWIFT wire	Create (pending) → Execute
`TRANSFER_TYPE_ACH`	ACH debit/credit	Create (pending) → Execute
`TRANSFER_TYPE_ADMIN_CREDIT`	System credit (via `CreditTransfer` RPC)	Immediate
`TRANSFER_TYPE_ADMIN_DEBIT`	System debit (via `DebitTransfer` RPC)	Immediate

Recipient payloads (`oneof recipient`)

Admin contra (`AdminContra`)

Used by CreditTransfer / DebitTransfer for double-entry settlement:

Enum	Ledger behaviour
`ADMIN_CONTRA_SETTLEMENT` (default)	Customer ↔ provider settlement account (`system_provider_settlement`)
`ADMIN_CONTRA_EXTERNAL`	Top-up / withdrawal treated as external nostro (no settlement mirror)

Settlement account resolved via accounts.provider_id + provider_settlement_accounts(provider_id, currency).

Example: outbound SEPA payout

1. CreateTransfer - adapter submits payout after user initiates transfer (or adapter receives outbound instruction):

{
  "idempotency_key": "cc-pay-abc123",
  "type": "TRANSFER_TYPE_SEPA",
  "from_account_id": "550e8400-e29b-41d4-a716-446655440000",
  "amount": "1500.00",
  "currency": "EUR",
  "description": "Payout to beneficiary",
  "sepa": {
    "name": "John Doe",
    "iban": "DE89370400440532013000",
    "currency": "EUR"
  },
  "external_reference": "cc-payment-id-789",
  "source_service": "currencycloud-adapter",
  "metadata": { "cc_beneficiary_id": "ben-456" },
  "actor": { "type": "ACTOR_TYPE_SERVICE", "id": "currencycloud-adapter" }
}

Response:

{
  "transfer_id": "7c9e6679-7425-40de-944b-e07fc1f90ae7",
  "status": "TRANSFER_STATUS_PENDING",
  "fee_amount": "2.50",
  "hold_id": "hold-uuid"
}

2. ExecuteTransfer - after provider confirms settlement:

{
  "transfer_id": "7c9e6679-7425-40de-944b-e07fc1f90ae7",
  "idempotency_key": "cc-exec-abc123",
  "actor": { "type": "ACTOR_TYPE_SERVICE", "id": "currencycloud-adapter" },
  "metadata": { "cc_settlement_ref": "settle-999" }
}

On execute, ledger posts double-entry: debit customer, credit provider settlement account (principal); fee leg to system_fee_revenue if applicable.

Example: inbound credit (crypto sell)

crypto-service calls CreditTransfer when user sells crypto for fiat:

{
  "idempotency_key": "sell-order-42",
  "account_id": "550e8400-e29b-41d4-a716-446655440000",
  "amount": "500.00",
  "currency": "EUR",
  "description": "Crypto sell proceeds",
  "reference": "order-42",
  "contra": "ADMIN_CONTRA_SETTLEMENT",
  "external_reference": "onchain-tx-hash",
  "source_service": "crypto-service",
  "actor": { "type": "ACTOR_TYPE_SERVICE", "id": "crypto-service" }
}

Transfer status lifecycle

CardPaymentService

Proto: finance-service/proto/finance/v1/card_payment.proto

Card processor adapter debits the account linked to a card (authorization / clearing).

RPC	Purpose
`CreateCardPayment`	Debit card-linked account (purchase)
`ReverseCardPayment`	Refund or chargeback against original transfer

Example:

{
  "idempotency_key": "auth-001",
  "card_id": "card-uuid",
  "amount": "25.99",
  "currency": "EUR",
  "description": "Purchase",
  "mcc": "5411",
  "merchant_name": "Supermarket XYZ",
  "merchant_id": "MERCH-123",
  "authorization_code": "ABC123",
  "external_reference": "proc-tx-456",
  "source_service": "marqeta-adapter",
  "actor": { "type": "ACTOR_TYPE_SERVICE", "id": "marqeta-adapter" }
}

FXRateService

Proto: finance-service/proto/finance/v1/fx_rate.proto

Market-data adapters publish FX rates; crypto-service reads them via ListFXRates.

RPC	Purpose
`UpsertFXRate`	Publish single rate pair
`BatchUpsertFXRates`	Publish many rates in one call
`ListFXRates`	Read all current rates

source_service must match actor.id; actor type must be ACTOR_TYPE_SERVICE.

TransactionStatementService

Proto: finance-service/proto/finance/v1/transaction_statement.proto

Read-only ledger statement for back-office and reporting integrations. Mirrors admin REST GET /v1/admin/transactions/statement (permission transfers:read).

RPC	Purpose
`ListTransactionStatement`	Paginated ledger lines with optional account/user scope and date range

Scope (`StatementScope`)

Enum	REST equivalent	Required fields
`STATEMENT_SCOPE_ALL`	No `account_id` / `user_id`	`from_date`, `to_date`
`STATEMENT_SCOPE_ACCOUNT`	`account_id` query param	`account_id`, `from_date`, `to_date`
`STATEMENT_SCOPE_USER`	`user_id` query param	`user_id`, `from_date`, `to_date`

account_id and user_id are mutually exclusive. Date range is inclusive (YYYY-MM-DD), max 366 days.

Request / response

Response: items[], next_cursor, has_more. For CSV export use REST with format=csv (streams all pages).

Example (grpcurl)

provider.v1 - Outbound APIs (finance calls adapter)

External payment/card providers implement these services. Finance calls them when providers.yaml routes an account type or card product to type: grpc.

Proto: finance-service/proto/provider/v1/account.proto, card.proto

AccountProviderService

RPC	When finance calls
`OpenAccount`	User opens account; finance needs real IBAN / external ID
`CloseAccount`	Before local account close

Finance persists provider_id and external_id on the accounts row.

CardProviderService

RPC	When finance calls
`IssueCard`	Card issuance
`GetCardNumber`	PAN reveal (PCI - never stored in finance DB)
`GetCardCVV`	CVV reveal
`BlockCard` / `UnblockCard`	Sync block state with processor

Payment provider integration guide

This section describes how to build a deployable adapter (e.g. Currencycloud, Marqeta) that connects to CustodyCore.

Architecture

A payment provider integration is two gRPC relationships, not one:

Concern	Direction	Proto
Account / card provisioning	finance → adapter	`provider.v1`
Outbound transfers (SEPA/SWIFT/ACH)	adapter → finance	`finance.v1.TransferService`
Inbound credits	adapter → finance	`CreditTransfer`
Card authorizations	adapter → finance	`finance.v1.CardPaymentService`

Transfers are never exposed as outbound gRPC from finance to the adapter. The adapter receives provider webhooks and calls finance inbound gRPC.

Step-by-step checklist

1. Scaffold adapter service

services/integrations/{provider}/
├── cmd/main.go
├── internal/
│   ├── webhook/          # provider → adapter HTTP
│   ├── providerclient/   # adapter → provider REST/SDK
│   └── financeclient/    # adapter → finance gRPC
└── deploy/

No public routes through api-gateway. Adapter runs in-cluster only.

2. Implement provider.v1 (if provisioning accounts/cards)

Run gRPC server on e.g. {provider}-adapter:9100:

3. Register settlement accounts

Before live credits/debits/executes, seed finance DB:

Customer accounts opened via the provider must have accounts.provider_id = 'currencycloud'.

Without this mapping, CreditTransfer, DebitTransfer, and ExecuteTransfer fail with FAILED_PRECONDITION.

4. Implement transfer webhook flow

Typical outbound SEPA sequence:

Adapter-initiated flow (provider drives timing):

Provider webhook: outbound payment requested

Adapter → CreateTransfer (SEPA/SWIFT/ACH) with external_reference

Adapter calls provider API to send funds

Provider webhook: settled

Adapter → ExecuteTransfer with settlement ref in metadata

Store mapping external_reference → transfer_id in adapter DB for idempotent webhook handling.

5. Implement inbound credit flow

Provider webhook: incoming wire / deposit detected

Resolve finance account_id (via IBAN mapping or external_id)

Adapter → CreditTransfer with unique idempotency_key per provider event

Default contra=ADMIN_CONTRA_SETTLEMENT mirrors funds from settlement account

6. Wire finance gRPC client (Go example)

Reference implementation: crypto-service/internal/infrastructure/financeclient/client.go

7. Test with grpcurl

Port-forward finance gRPC (dev):

List services:

Describe RPC:

Call (requires proto import paths or server reflection if enabled):

Server reflection may not be enabled in production; use generated stubs or -proto / -protoset flags with grpcurl.

Default local provider (no adapter)

Without PROVIDERS_CONFIG, finance uses the built-in local provider:

Accounts: synthetic IBAN via NumberFactory + PostgreSQL sequence

Cards: mock last-four from BIN prefix

provider_id = "local", empty external_id

Settlement accounts seeded for local + EUR/USD

Use local provider for development; switch routing in YAML when adapter is ready.

identity.v1 - IdentityInternal

Address: identity:9090
Proto: identity-service/proto/identity/v1/identity.proto

RPC	Purpose	Callers
`ValidateStepUpToken`	Verify step-up MFA token + operation type	api-gateway plugin, finance REST
`GetUserContact`	Email and phone for notifications	notification, compliance
`GetUserProfile`	Name, address, customer type	notification, compliance
`ResolveUserID`	Lookup user by email or phone	finance (P2P transfers)

ValidateStepUpToken request:

compliance.v1 - ComplianceInternal

Address: compliance:9090
Proto: compliance-service/proto/compliance/v1/compliance.proto

RPC	Purpose	Callers
`GetKYCStatus`	KYC gate before financial operations	finance-service

Finance checks operations_allowed during transfer pipeline execution. Adapters do not call compliance directly - finance enforces it.

Quick reference - all RPCs

finance.v1.TransferService

RPC	Required fields
`CreateTransfer`	`idempotency_key`, `type`, `from_account_id`, `amount`, `currency`, `recipient`, `source_service`, `actor`
`ExecuteTransfer`	`transfer_id`, `idempotency_key`, `actor`
`CancelTransfer`	`transfer_id`, `idempotency_key`, `actor`
`CreditTransfer`	`idempotency_key`, `account_id`, `amount`, `currency`, `source_service`, `actor`
`DebitTransfer`	`idempotency_key`, `account_id`, `amount`, `currency`, `source_service`, `actor`
`GetTransfer`	`transfer_id`

finance.v1.CardPaymentService

RPC	Required fields
`CreateCardPayment`	`idempotency_key`, `card_id`, `amount`, `currency`, `source_service`, `actor`
`ReverseCardPayment`	`idempotency_key`, `original_transfer_id`, `actor`

finance.v1.FXRateService

RPC	Required fields
`UpsertFXRate`	`from_currency`, `to_currency`, `rate`, `source_service`, `actor`
`BatchUpsertFXRates`	`rates[]`, `source_service`, `actor`
`ListFXRates`	-

finance.v1.TransactionStatementService

RPC	Required fields
`ListTransactionStatement`	`scope`, `from_date`, `to_date`, `source_service`; plus `account_id` when scope is account, or `user_id` when scope is user

provider.v1 (implemented by adapter)

Service	RPCs
`AccountProviderService`	`OpenAccount`, `CloseAccount`
`CardProviderService`	`IssueCard`, `GetCardNumber`, `GetCardCVV`, `BlockCard`, `UnblockCard`

identity.v1.IdentityInternal

RPC	Required fields
`ValidateStepUpToken`	`token`, `user_id`, `operation_type`
`GetUserContact`	`user_id`
`GetUserProfile`	`user_id`
`ResolveUserID`	`email` or `phone`

compliance.v1.ComplianceInternal

RPC	Required fields
`GetKYCStatus`	`user_id`

General

gRPC Integrations#

Overview#

Connectivity#

Kubernetes (production / Minikube)#

Call matrix#

Conventions#

Amounts and IDs#

Actor#

Idempotency#

Traceability fields#

Errors#

Authentication (target production setup)#

finance.v1 - Inbound APIs (adapters call finance)#

TransferService#

Transfer types (TransferType)#

Recipient payloads (oneof recipient)#

Admin contra (AdminContra)#

Example: outbound SEPA payout#

Example: inbound credit (crypto sell)#

Transfer status lifecycle#

CardPaymentService#

FXRateService#

TransactionStatementService#

Scope (StatementScope)#

Request / response#

Example (grpcurl)#

provider.v1 - Outbound APIs (finance calls adapter)#

AccountProviderService#

CardProviderService#

Payment provider integration guide#

Architecture#

Step-by-step checklist#

1. Scaffold adapter service#

2. Implement provider.v1 (if provisioning accounts/cards)#

3. Register settlement accounts#

4. Implement transfer webhook flow#

5. Implement inbound credit flow#

6. Wire finance gRPC client (Go example)#

7. Test with grpcurl#

Default local provider (no adapter)#

identity.v1 - IdentityInternal#

compliance.v1 - ComplianceInternal#

Quick reference - all RPCs#

finance.v1.TransferService#

finance.v1.CardPaymentService#

finance.v1.FXRateService#

finance.v1.TransactionStatementService#

provider.v1 (implemented by adapter)#

identity.v1.IdentityInternal#

compliance.v1.ComplianceInternal#
